Low Slope Roofing Systems Supplies

NB Handy carries a full inventory of all the supplies required to complete most any Commercial Low Slope installation. Below is a list of the product categories we carry along with the brand link for access to additional information. Please call your local NB Handy branch for assistance in obtaining pricing and products.

Insulation & SheathingLearn More

InsulBase Flat Polyiso

  • Highest thermal performance available
  • Most economical polyiso
  • No cover board required
  • Quality Mark Certified LTTR values
  • Free of CFC's and ozone depleting components
  • Environmentally friendly construction with 0% ozone-depleting components and CFC free
  • Approved for direct application to steel

InsulBase is a rigid roof insulation panel composed of a closed-cell polyisocyanurate foam core bonded on each side to fiber-reinforced facers.
InsulBase polyiso insulation provides the highest R-value per inch of commercially available insulation products.

InsulBase Flat Polyiso Details

SecurShield Polyiso

  • Coated glass fiber facer provides superior wind and fire resistance
  • UL Class A Rated over wood decks without thermal barrier
  • Top rated with Factory Mutual at 1-255
SecurShield Polyiso Details

Tapered Panels

  • InsulBase Tapered is also available for use with extended panel system
  • InsulBase Tapered is a sloped, rigid roof insulation panel composed of a closed-cell polyisocyanurate foam core bonded during the manufacturing process to fiber reinforced facers.
  • InsulBase Tapered is designed to promote positive drainage and prevent ponding water.
Tapered Panel details

Extended Panel Profiles

  • Tapered SecurShield™ – premium-performance coated fiberglass facer, for cold-applied and spray-applied applications
  • D, E, F, FF, Z, ZZ and QQ are the extended panels and are also available in Pre-cut Hips and Valleys
  • Hinged Target® Sump – Hinged 8' x 8' Sump, pre-assembled in one piece
Extended Panel Profiles Details

Hinged Target® Sump

Reduces Field Labor
  • One piece, ships 4' x 8', folds out to 8' x 8'
  • Pre-cut, ready to install
  • Factory assembled
  • Concentric circles simplify drain cutout
Completely Eliminates Waste
  • Reduces dumpster fees
  • Reduces dumpster fees
Custom Sizes Available for Optimum Drainage
  • Multiple thicknesses and slopes to accommodate specific job conditions
  • Flexible starts at the drain ½", 1", 1½", or 2"
  • FM Class 1 Assemblies – 1½" or 2" starts are available
  • Perimeter edge thicknesses 1½", 2", 2½", 3", 3½"
  • Available with Carlisle's Tapered HP and Tapered InsulBase
  • Tapered InsulBase SecurShield™ facers in 20 or 25 psi
Hinged Target® Sump Details

Pre-cut Hips and Valleys

Designed specifically for four-way tapered polyiso installations

Pre-cut Hips (slope outward) and Pre-cut Valleys (slope inward) are factory produced using two 4' x 4' panels of Tapered InsulBase, or Tapered SecurShield™, and then cut in half at a 45-degree angle. Only the two halves that you need are shipped.

PreCut Hips and Valleys Details

Expanded Polystryrene Insulation

Designed specifically for four-way tapered polyiso installations
  • A rigid polystyrene insulation board, Carlisle Sure-Seal EPS delivers an excellent insulation value. It is available in straight and tapered configurations plus as a composite form with HP Recovery Board.
  • It is a proven performer as an insulation board under Carlisle Design B Ballasted System or as an insulating or tapered underlayment to HP Recovery Board or polyisocyanurate HP for use in Carlisle Design A Fully-Adhered and Mechanically-Fastened Roofing Systems.
Hinged Target® Sump Details

Insulfoam SP

InsulFoam SP is an advanced roof insulation consisting of a superior closed-cell, lightweight and resilient expanded polystyrene (EPS) with a durable and stable, factory-laminated fiberglass facer.
InsulFoam SP has a nominal density of 1.25 lb/ft³ (pcf), and meets or exceeds the requirements of ASTM C578, Type VIII, Standard Specification for Rigid, Cellular Polystyrene Thermal Insulation.

  • Premium facer improves fire resistance, moisture resistance and dimensional stability
  • Fire-rated slip sheet and thermal barrier not required for many applications
  • Recognized by the International Code Council Evaluation Service
  • Numerous Underwriters Laboratory and Factory Mutual Approvals
  • Contains no formaldehyde or ozone-depleting HCFCs
  • Features up to 25% recycled material
  • 100% recyclable foam core
Insulfoam SP Details

XPS

STYROFOAM™ Brand DECKMATE™ Insulation is a Type X extruded polystyrene foam product designed for use in conventional low-slope roof applications.

It can be installed directly on structural steel decks beneath a sheet membrane or a standing seam metal roof, eliminating the need for a thermal barrier such as gypsum board.

XPS Information

Owens Corning PINK® Foam Insulation

  • Comprehensive Line of Products
  • Wide choice of sizes, thicknesses and edges
  • Strengths available, from 20 to 100 psi
  • Available unfaced or with film facing
  • Exceptional Moisture Resistance
  • Resists moisture and retains R-Value
  • Resists common acid soils and decay
  • Superior Insulating Properties
  • High, stable R-Value (5 per inch)
  • Ease of Use
  • Easy to handle, score, cut, and install no special tools needed
Owens Corning PINK® Details

Fiberboard

  • Carlisle HP Recovery Board is a rigid insulating and recovery board.
  • It is available in either 1/2 inch (13mm) or 1 inch (25 mm) thickness.
  • This dimensionally stable, durable insulation is compatible with all Carlisle Single-Ply Roofing Systems.
Fiberboard Information

Asphalt & AccessoriesLearn More

Asphalt

  • Bulk
  • 50lb Units

Asphalt Accessories

  • Fiberboard
  • Cant Strip and Tapered Edge
  • Felt Underlayment #15, #30, #40, #90
  • Mops, Staples, and Handles

Cements & CoatingsLearn More

Screws & FastenersLearn More

Polymer Fastening Bar

The Polymer Fastening Bar is an engineered polymer bar that's used to mechanically fasten EPDM membranes per Carlisle Specifications.

The bar is packaged in a 1˝ x 250´ coil that has pre-punched holes every 3˝ on center.

Polymer Fastening Bar

Termination Bar

The Termination Bar is an extruded aluminum bar that's designed for securing and sealing compression type flashing terminations per Carlisle Specifications.

The bar is packed with 1' x 10' lengths, 500 linear feet per package and has pre punched holes every 6 inches on center.

Termination Bar

Metal Fastening Bar

The Metal Fastening Bar is a Galvalume™ coated metal that's used to mechanically fasten EPDM membranes per Carlisle Specifications.

The bar is packaged in 1˝ x 10´ lengths, 500 linear feet per package and has pre-punched holes every 6˝ on center.

Metal Fastening Bar

Sure-Seal Ballast Retaining Bar

The Ballast Retaining Bar is an extruded aluminum bar that's designed as a ballast retaining perimeter securement system, which comes packaged in 4˝ x 10´ lengths, 250 linear feet per package.

The ballast retaining bar has pre-punched holes every 6˝ on center for installation, and also has pre-punched drainage holes every 4˝ on center.

Sure-Seal Ballast Retaining Bar Details

HP-X Fasteners and Piranha Plate

Carlisle HP-X Fasteners are used with Carlisle's Piranha Fastening Plate to secure Mechanically-Fastened Sure-Weld TPO and Sure-Flex PVC Roofing systems.

The HP-X Fastener is used on steel decks 20 gauge (0.91 mm) or 22 gauge (0.76 mm) or wood (minimum 15/32" [12 mm] CDX plywood).

The HP-X Fastener is designed to offer an optimum combination of driving performance, back-out and corrosion resistance with excellent pull-out performance.

HP-X Fasteners

HP-XTRA Fasteners and Piranha Xtra Plate

Carlisle HP-XTRA Fasteners are used with Carlisle's PIRANHA™ XTRA Fastening Plates to secure Mechanically Fastened Sure-Weld roofing Systems. The HP-XTRA Fastener is an oversized diameter (0.315") steel threaded fastener for use with 22 gauge (0.76 mm) steel decks for maximum pullout.

HP-XTRA Fasteners and Piranha Xtra Plate Details

Insulation Fastening Plates

Carlisle Insulation Fastening Plates are specifically designed for attachment of insulation under Carlisle roofing systems.

Insulation Fastening Plates are stamped from Galvalume®-coated steel for long-term protection against corrosion.

HP-X Fasteners

SureSeal® Seam Fastening Plates

Carlisle Seam Fastening Plates are specifically designed for use with RUSS™ or membrane securement for reinforced EPDM/TPO membrane when specified in the current Carlisle specifications and details.

Seam Fastening Plates can also be used for securing insulation on Sure-Seal, Brite-Ply™, or Sure-Weld™ Mechanically-Fastened or Metal Retrofit Roofing Systems.

SureSeal® Seam Fastening Plates Details

PaversLearn More

Plaza Paver System

Carlisle has partnered with Hanover Architectural Products, the premier manufacturer of concrete pavers, to offer our customers the Carlisle Plaza Paver System.

  • Pavers are manufactured to provide the highest level of performance, with a minimum 8,500 psi compressive strength.
  • Pavers are available in various sizes and weights. The most common size is a 2˝-thick paver with a nominal 2´x 2´ dimension weighing 25 lbs. per square foot
  • Pavers are available in 8 standard colors, with an optional 3,000 additional colors.
  • Pavers can contribute toward LEED credit requirements.

Colors


Pedestal Paver

Pedestal Paver is available in 2´ x 2´ x 2 ¼˝ size in tudor or diamond finish, and weighs 22 lbs/ft². The Pedestal Paver incorporates footing in the center and each corner of the paver to provide ½˝ of clearance for exceptional storm water drainage.


EPDM Pedestal

The EPDM Pedestal is manufactured using EPDM to provide a raised 3/8" fixed height for architectural and ballast applications.

This pedestal incorporates1/8"vertical spacer tabs and horizontal leveling shims of 1/8" or 1/16 to make installation easy.


High-Tab Pedestal

The High-Tab Pedestal provides a raised 3/8" height for all paver applications. Multiple High-Tab Pedestals can be combined to provide additional height where necessary.

This pedestal incorporates 1/8"vertical spacer tabs and horizontal leveling shims of 1/8" (white shim) or 1/16 "(black shim) to make installation easy.


Elevator Pedestal

Elevator Pedestals provide the ability to raise all paver systems to a desired height in order to create a monolithic appearing roof system.

Elevator Pedestal assemblies are available in 2˝, 3˝ and 4˝ models and can be combined for heights up to 16˝. With additional bracing, the Elevator Pedestal can provide up to 24˝ in height.


Compensator

The Compensator is a specially designed tapered circular base for use with Hanover's High-Tab and Elevator Pedestals. One Compensator will provide up to1/8"of roof slope compensation to eliminate the slope of most roofs to allow for a level paver installation. Multiple Compensators can be combined to allow for additional roof slope.


MRP Supports

As a new member of the Marathon Companies which has been a leader in the manufacturing and master distributors of commercial roof drains, vents, equipment and accessories. MRP Supports is commited to providing its significant distributor network, architects, specifiers and ultimately the contractor with quality paver support products, competitive prices and the best customer service in the industry.

Established as a standalone corporation, MRP Supports was separated from Marathon Roofing Products, another member of the Marathon Companies. In January 2014 to ensure that both of the successful entities continue to provide exceptional service to their customers respectively. With the backing and knowledge of the Marathon Companies, it will be certain that our new endeavor will have great success in the future.

MRP Supports Site

Sure-Seal® Rubber Pavers

Carlisle's Rubber Pavers are designed to meet Carlisle's demanding specifications for a roof paver. These pavers are 2´ x 2´ x 2˝ thick and weigh 6 lbs./ft². The pavers consist of 90% post-consumer recycled content, providing an environmentally friendly product that provides superior protection of underlying roof membranes.

With Carlisle's Interlocking Paver System, the pavers are loose-laid and interlocked over the membrane, offering premium membrane protection without limiting accessibility to the membrane.

Sure-Seal® Rubber Paver Details

Pressure–Sensitive Molded Walkway Pads

Let Carlisle simplify your next EPDM installation with their Pressure-Sensitive Walkway Pads. The Carlisle Walkway Pad is designed to protect the membrane in those areas exposed to repetitive foot traffic.

  • Excellent tear and puncture resistance
  • UV resistant
  • Slip resistant
  • Available in both black and white
Pressure–Sensitive Molded Walkway Pad Details

Sure–White Pressure Sensitive Walkway Pads

Let Carlisle simplify your next Sure-White EPDM installation with their Pressure-Sensitive Walkway Pads. The Carlisle Walkway Pad is designed to protect the membrane in those areas exposed to repetitive foot traffic.

Sure–White Pressure Sensitive Walkway Pad Details

Sure-Flex™ Heat Weldable Walkway Rolls

The Carlisle Sure-Flex Heat Weldable Walkway Roll is designed to protect Sure-Flex membrane in those areas exposed to repetitive foot traffic and other hazards.

The Carlisle Sure-Flex Heat Weldable Walkway Roll is recommended for use with all Carlisle Sure-Flex Roofing Systems. The Carlisle Sure-Flex Heat Weldable Walkway Roll is weather resistant and offers excellent tear and puncture resistance. Walkway Rolls are gray in color and incorporate an aggressive, non-slip, diamond tread pattern.

Sure-Flex™ Heat Weldable Walkway Roll Details

Sure-Weld® Walkway Rolls

The Carlisle Sure-Weld Heat Weldable Walkway Roll is designed to protect the Sure-Weld membrane in those areas exposed to repetitive foot traffic and other hazards.

  • Increased slip resistance created with a diamond plate tread pattern
  • Walkway edges are trimmed in safety yellow to better define the designated traffic flow
  • The yellow edges are smooth without tread lugs for easier welding
  • Superior weathering package for long term performance
  • Stocked in white, tan and gray, special colors available (minimums apply)
Sure-Weld® Walkway Roll Details

WaterproofingLearn More

Below Grade. Above Grade. Blindside

For more than 45 years, Carlisle Coatings & Waterproofing solutions have led the way in providing watertight, reliable waterproofing solutions to suit varied building site solutions. Offering time-tested systems and innovative solutions that incorporate the latest waterproofing technologies.

Applications
  • Bentonite clay Waterproofing
  • Fluid-Applied Waterproofing
  • Hot-Applied Waterproofing
  • Pre-Pave Sheet Waterproofing
  • Self-Adhering Blindside
  • Self-Adhering Sheet Waterproofing
  • Sheet-Applied Waterproofing
  • Spray-Applied Waterproofing
Waterproofing Products

Perimeter Sheet Metal & Flashing SystemsLearn More

Sure-Seal® Termination Bar

The Sure-Seal Termination Bar is an extruded aluminum bar designed for securing and sealing flashing terminations in accordance with current Carlisle Specifications.

  • Corrosion resistant 6063-T6 extruded aluminum
  • Pre-Punched 6" (150 mm) o.c. and 1" (25 mm) from each end
  • Carlisle logo stamped on each section
  • Sealant ledge to hold the Lap Sealant and provide stability
  • Serrated back provides increased surface area contact with membrane to compress the Water Cut-Off Mastic

Fastening and Termination Bars Product Data Sheet

SecureSeal® Drip Edge

  • Economical prefab metal edge
  • Concealed splice plates for smooth, unbroken appearance
  • Pre-punched holes and supplied fasteners for proper attachment and fast installation
  • ANSI/SPRI ES-1 Certified
SecureSeal® Drip Edge Details

SecurEdge 200 Coping

  • FM 1-90 Approved 20-year painted finish
  • Miami-Dade approved (No. 08-0604.02 12/11/13) to comply with "High Velocity Hurricane Zone of the Florida Building Code"
  • Single-source, full roof system warranty
  • Full snap-on design and 12' lengths simplifies installation with no crimping
  • No unsightly cover plates
  • Dual non-curling sealant strips allow for thermal movement
  • Pre-punched fastening holes ensure proper installation
  • Factory-fabricated accessories improve aesthetics
  • RE-3 blow-off resistance: 24 Ga. & .040 – 140 lbs/ft²
  • RE-3 blow-off resistance: .050 & .063 – 180 lbs/ft²
SecurEdge 200 Coping Details

SecurEdge One Fascia (MF/FA Single Ply)

  • 12' lengths for quicker installs and lower labor costs
  • Non-penetrating design eliminates stripping in and heat welding
  • Pre-punched fastening holes ensure proper installation
  • Slotted fastening holes allows for thermal movement
  • RE-1: passed
  • RE-2 blow-off resistance: 400 lbs/ft²
  • Express color selection along with a standard size of 3"
SecurEdge One Details

Roof DrainsLearn More

Roof Drains are an effective year-round solution to removing water from the roof surface in all weather and all seasons. Interior Roof Drains have the advantage over gutters and downspouts because interior Roof Drains are maintained at the interior building temperature and are far less likely to freeze and back up in harsh northern climates. With the advent of sloped roof decks and tapered insulations, it has also become necessary to include Overflow Roof Drains to relieve dangerous overloading of the structural system caused by heavy ponding water.


Sure-Seal® Insert Drain Systems

Sure-Seal Insert, Vandal Resistant and Add-On Drain models are ideally suited for the roofing market and are extremely cost effective when compared to removing and replacing existing drain bowls with the related plumbing costs.

The Sure-Seal Insert Drain has been engineered with significant performance and installation advantages compared to the competition.

  • 14" (356mm) diameter .080" (2mm) aluminum strainer
  • 141 square inches (916.5 sq. cm.) of Flow-Through open area
  • Recessed clamping ring
  • 8 stainless steel studs with lock nuts
  • Pre-punched 18" (451mm) square aluminum flange
  • Mechanical Backflow Seal with 50 shore A urethane
  • Safety yellow color strainer
  • Add-On model connects with 4" (101.6mm) o.d. cast iron or PVC pipe
  • 7/16" (11.1mm) wrench needed for installation

8" Intimidator Aluminum Drain

Our new 8" "Intimidator' Spun Aluminum retrofit drain with clamping ring. Standard with ABS clamping ring and plastic strainer. Optional upgrades include expanding tape, metal ring and strainer.

Brochure Installation Instructions

Aluminator Drain

NEW Aluminator ALL Aluminum Retrofit Drain with Aluminum Body, Heavy Duty Aluminum Ring, Aluminum Strainer and ProSeal Rubber Seal. Constructed of heavy gauge Spun Aluminum (.081) that is available in sizes of 3", 4', 5" and 6". Includes strong mechanical seal that prevents water back-up issues.

Brochure Installation Instructions

Aluminum Fast Flow

Aluminum Fast Flow Drain is a Aluminum Drain that features a 2" wide band of high density expanding foam tape impregnated with asphalt for water back-up prevention

Brochure Installation Instructions

Economy Aluminum Drain

Our NEW Economy Aluminum Drain that is available in 2", 3" and 4" Retrofit applications. Spun Aluminum Drain with a 5" Aluminum Bolt Down Strainer

Brochure Installation Instructions

Cast Pak/RD1

Cast Pak drain is our assembled kit of the RD1drain with all the components for easy installation. Made of epoxy coated cast iron body that is supplied with an aluminum clamping ring, underdeck clamp, rubber coupling and strainer

Brochure Spec Sheet

Cast Pak/RD1

Large Body Cast Iron drain constructed to withstand climate and the rigors of long-term use. Available 2" - 4" pipe sizes with many optional accessories and with 12" x 12" Promenade Top

Brochure Spec Sheet

RD200 Small Body

Small Body Cast Iron drain constructed to withstand climate and the rigors of long-term use. Available 2" - 4" pipe sizes with many optional accessories

Brochure Spec Sheet

RD200CP

Small Body Cast Iron drain constructed to withstand climate and the rigors of long-term use. Available 2" - 4" pipe sizes with many optional accessories and with 8" x 8" Promenade Top

Brochure Spec Sheet

RD230

Small Body Cast Iron drain constructed to withstand climate and the rigors of long-term use. Available 2" - 4" pipe sizes with many optional accessories and with 8" x 8" Promenade Top

Brochure Spec Sheet

RD240

Cast Iron Balcony Drain with bronze dome, threaded outlet available in sizes 2" - 4"

Brochure Spec Sheet

RD250

One Piece Cast Iron combination Drain & Secondary Overflow

Brochure Spec Sheet

RD260

Small Area "Dual" Overflow Cast Iron Package

Brochure Spec Sheet

RD27 scupper

Heavy duty Cast Iron Scupper Drain for horizontal and vertical drainage for parapet applications.

Brochure Spec Sheet

RD280

One Piece Cast Iron Drain with deck flange, drain body, flashing clamp and self locking cast iron dome

Brochure Spec Sheet

RD280-SO

One Piece Cast Iron Side Outlet Drain with deck flange, drain body, flashing clamp and self locking cast iron dome

Brochure Spec Sheet

RD300 Extra Large Body

Extra Large Body Cast Iron drain constructed to withstand climate and the rigors of long-term use. Available 3" - 10" pipe sizes with many optional accessories

Brochure Spec Sheet

RD680

Vandal resistant epoxy coated vent cap available sizes 2" - 4"

Brochure Spec Sheet

RD700 Dual Overflow

Vandal resistant epoxy coated vent cap available sizes 2" - 4"

Brochure Spec Sheet

RD940

Nickel Bronze Downspout nozzle available sizes 2" - 4", no hub and also threaded outlets

Brochure Spec Sheet

Century

Copper drain that is available with 14"(economy) or 18"(premium) flange diameter for direct connect applications.

Brochure Installation Instructions

Coppertite

Coppertite Drain is a Copper Drain that features a 2" wide band of high density expanding foam tape impregnated with asphalt for water back-up prevention

Brochure Installation Instructions

Diamond Series

Copper Drain for retrofit applications.

Brochure

Diamond Series

Proliner Drain is the only drain in the industry that provides multiple seals for water back-up prevention.

Brochure

Proseal

Copper Drain supplied with ProSeal mechanical seal for water back-up prevention

Brochure Installation Instructions

Side Outlet Copper

Horizontal discharge copper drain to route water laterally in shallow access areas. Available in 2" - 4" pipe sizes

Brochure Installation Instructions

Dura

Thermoplastic rubber Retrofit Drain that is highly resistant ti ultraviolet sunrays, other atmospheric and chemical conditions. Compatible with BUR, Modified and EPDM

Brochure

ENPOCO/ULRD

Enpoco Pak drain is our assembled kit of the ULRD drain with all the components for easy installation. Made of injected molded PVC that is supplied with an aluminum clamping ring, underdeck clamp, rubber coupling and strainer

Brochure Spec Sheet

TOOLSLearn More

We offer a complete line of Malco Tools including the following:


Gutter & Downspout

  • Aprons
  • Caulking Guns
  • Drill Bits
  • Gutter & Downspout Tools
  • Hack Saws & Blades
  • Hammers
  • Hand Riveters
  • Hole Punches
  • Measuring - Chalk Lines & Squares
  • Measuring - Tape Measures
  • Measuring - Wheels & Rules
  • Nut Drivers
  • Pouches
  • Power Drivers
  • Rivets
  • Saw Blades - Circular
  • Screw / Anchors
  • Seamers, Folding Tools & Brake
Malco Tools Freund Tools

Roofing - Asphalt

  • Aprons
  • Caulking Guns
  • Hammers
  • Knee Pads
  • Knives & Blades
  • Magnetic Sweeps
  • Measuring - Chalk Lines & Squares
  • Measuring - Tape Measures
  • Measuring - Wheels & Rules
  • Pouches
  • Power Assisted Cutters / Shears / Driver
  • Roofing Tools - Asphalt
  • Saw Blades - Circular
  • Saw Blades - Hole Saws
  • Saw Blades - Reciprocating
  • Seamers, Folding Tools & Brake

HEAT WELDING

HAPCO Inc

BAK RiOn

Features
  • Comparable to LEISTER Triac, but with higher airflow.
  • Field tested.
  • Optimal performance/best price.
  • High speed welding enables high production.
  • Easy welding with ergonomic handle.
  • Maintenance friendly.
  • High quality.
  • Large range of accessories available.

BAK LarOn

Features
  • Comparable to the LEISTER Varimat.
  • Ideal weight distribution guarantees smooth welding.
  • Service friendly thanks to standard electronics.
  • Digital display for temperature & speed.
  • Automatic startup system.
  • Steady and building site friendly design to weld all thermoplastic roofing materials and membranes.
  • Robust, efficient & cost effective

BAK TarpOn

Features
  • Comparable to the LEISTER Uniplan.
  • Electronically regulated temperature adjustable 20 to 650 ° C.
  • Stepless adjustable airflow-volume 50-100%
  • Digital display of speed, temperature, and airflow.
  • Speed adjustable from 0.5 to 12m/min
  • Automatic start function.
  • Foldless welding, high weld speed.

BAK LarOn Deluxe Kit

Features
  • Laron Deluxe kit with Gillete Generator.
  • Comparable to the LEISTER Varimat.
  • Ideal weight distribution guarantees smooth welding.
  • Digital display for temperature & speed.
  • Kit includes 100 foot heavy duty line cord.
  • 240V GFCI.
  • 12,500W Kleen Power Generator.
  • Convenient storage case for Laron.
  • All plugs and receptacles included.

BAK RiOn Deluxe Kit

Features
  • Comparable to LEISTER Triac, but with higher airflow.
  • Field tested and includes everything you need.
  • Optimal performance/best price.
  • High speed welding enables high product.
  • Easy welding with ergonomic handle.
  • Maintenance friendly.
  • High quality.
  • Large range of accessories available.

BAK RiOn Basic Kit

Features
  • Comparable to LEISTER Triac, but with higher airflow.
  • Field tested and includes a nozzle & roller.
  • Optimal performance/best price.
  • High speed welding enables high product.
  • Easy welding with ergonomic handle.
  • Maintenance friendly.
  • High quality.
  • Large range of accessories available.

Caulking & SealantsLearn More

Titebond® WeatherMaster™ Metal Roof Sealant

  • A polyether caulk specifically formulated to adhere to Kynar 500 finishes used in our Sentriclad Architectural Metal Program"
  • A one-component, non-priming sealant that features an Advanced Polymer technology proven to outperform urethanes and silicone sealants
  • Superior weather sealing performance – durability and strong UV-resistance
  • Low VOC formulation meets the most stringent State and Federal VOC regulatory requirements
  • Cold weather extrudability – extrudes down to 0°F
  • Fast tack-free-time – tack free in 1 hour or less (other technologies can remain tacky for 24 hours or more)
  • Excellent joint movement capability – up to 50%
  • GreenBuild approved
  • Plastic 10.1 oz tube
  • 12 tubes/box
  • Guns easily down to 0 degree
  • Available in all 30 Sentriclad colors
Titebond Details

Sonolastic NP 1

Sonolastic NP 1 is a versatile moisture-curing high performance polyurethane sealant with permanent elasticity

  • Joint movement capability ± 35% with excellent flexibility for keeping moving joints tight
  • Available in pro-pack sausages
  • Reduces job-site waste, lowers disposal costs
  • Easy to gun and tool
  • Speeds application and makes neater joints
  • Variety of colors
  • Matches common substrates
  • Bonds to most construction materials without a primer
  • Lowers installation costs
  • One component
  • No mixing, less labor
  • Weather resistant
  • Long-lasting weather tight seals
  • Wide temperature application range
  • Suitable for all climates
  • Paintable polyurethane sealant
  • Best choice for structures that may be repainted
  • Low VOC content
  • User friendly for applicators
  • Suitable for non-chlorinated water immersion
  • Potable water approved

Expansion JointsLearn More

Metalastic® SMF Straight Metal Flange Expansion Joint Cover


Additional Information

SOLDERLearn More

We supply all alloys in wire, bar, ingot, and cored wire. All wire solders are available in .032" dia to .500" dia.

  • Spool sizes 50, 25, 5, 1, 1/2, & 1/4
  • Standard Cast Bars 1# & 1 1/2#
  • Standard Extruded Bars 1#
  • Notch Bars 5# to 8# 5 sections
  • Meter Bars Industry Standard Size
  • Cast Bars 1 1/4" & 2" dia
  • Lead Free Body Solder 1/4", 1/2", & 3/8" dia
  • 1/2 Ingots 30# to 35#
  • Full Ingots 50# to 60#
  • Tri-Bar 1/4", 5/16", 7/16", & 3/8"

Vapor BarriersLearn More

725TR Air & Vapor Barrier/Temporary Roof

Carlisle's 725TR Air & Vapor Barrier/Temporary Roof is a 40-mil composite that consists of 35 mils of self-adhering rubberized asphalt laminated to a 5-mil polyolefin film. A siliconized release liner prevents the material from bonding to itself in the roll and is easily removed for installation. 725TR is available in a 244-square-foot roll with dimensions of 39" x 75'.

The factory-controlled thickness of the membrane ensures uniform barrier properties on the job, and the polyolefin film increases strength and has a non-skid surface suitable for the bonding of subsequent layers.


725TR Details

Vent StacksLearn More

725TR Air & Vapor Barrier/Temporary Roof

M-Weld® Pre-Flashed Accessories offer consistent, factory-built quality every time. The benefits include:

  • Consistent quality and ease of installation reduce the possibility of leaks and callbacks
  • Reduces installed costs by up to 6%!
  • No need to carry multiple repair membranes because M-Weld® Accessories work with torch, hot bitumen, or cold adhesive applied systems
  • Uniform construction results in a neater finished appearance
  • Wide variety of standard styles and sizes, plus custom-fabricated styles to meet specific job requirements

Standard M - Vent

Single size fits many different sized pipes:

  • Vent stacks
  • Faulty flashing around penetrations

Adjustable M- Vent

Easily flashes pipes up to 14":

  • Damaged flashing around tall or awkward pipes or protrusions

One Way Vent

Allow continuous release of vapor within system


Drain Insert

Complete with hardware, strainer, and gravel guard; Drain insert retrofits

  • Damaged interior drains and flashing

M-Curb System

Ideal for flashing and pitch pans around:

  • Guide wires, Antennas, Sign supports, & other difficult-to-flash areas, requires no strip flashing and easily bonds to most roofing materials

SkylightsLearn More

SunPath™ Tubular Daylighting Device (TDD)

Carlisle's SunPath TDD is a perfect complement to the company's revolutionary DryLight™ RIM-encapsulated skylights, providing increased daylighting opportunities for a variety of applications.

The SunPath TDD features a high-impact acrylic dome fused to an aluminum mounting ring that joins to a seamless aluminum flashing to provide unmatched strength and durability. The interior light tube utilizes an advanced reflection technology that provides superior light transmission and optimal interior daylighting.

  • 100% impact-modified acrylic domes
  • Unique rolled-lock aluminum retainer ring
  • Seamless aluminum flashing (.080 GA Series 1100)
  • Three (3) diffuser options for even light distribution
  • ENERGY STAR®-qualified for all climate zones
  • 98% reflective Alanod Miro-Silver lining
  • Eco-smart triple-glazed diffuser assembly (0.21 U-value / 0.26 SHGC)
  • Standard prismatic scatter disk insert within dome assembly
  • Three (3) dimmer system options (manual, switch-activated and IR remote)
  • Seamless aluminum curb cap flashing (no painted steel or plastic)
SunPath™ Tubular Brochure

Aluminum Welded Skylights

Curb Mount – Fixed

Manufactured to fit onto an existing curb, curb mount units are used to replace existing skylight hatches that are defective or in a state of glazing failure. Curb mount units can also be specified when the contractor prefers to field-fabricate his own curb, flash it into the roofing system, and then install a curb mount skylight onto it.


Curb Mount – Vented

Vented curb mounts provide the same benefits as the fixed curb mounts with an additional venting option, and can be operated manually or by motorization. If access to the rooftop through the skylight is required, egress hardware will be specified to allow the unit to swing like a door and, after the screen is removed, allow occupant access to the rooftop.


Self-Flashing Skylights – Fixed and Vented

These units are factory assembled onto a fully welded curb that is insulated with 1" rigid insulation and can be manufactured fixed or with several venting options. The 3" mounting flange allows for easy fastening to the deck.


Other Models and Options Available

Ridge lights, tandems, barrel vaults and tandems, among other items, are also available, along with additional glazing options, shapes and finishes. Call Carlisle Customer Service for a quote. Optional Pyramid Dome available on all acrylic and polycarbonate models.

Drylight Skylights
